49 decibels, quiet enough for hatchery rooms, aquarium plant rooms and clinical spaces.

AirSep Onyx Oxygen Concentrator

Up to 95.5% oxygen concentration, separated from ambient air by pressure swing adsorption.

Onyx gives 5 LPM at 9 PSI and Onyx Ultra gives 10 LPM at 20 PSI — pick on both the flow you need and the back pressure the unit has to overcome.

No — the compressor is built into the unit, so it runs from a power point with no external air supply.

Yes — regulator and flowmeter manifolds to connect the Onyx to Clearwater ozone generators are available separately.

Step up to an OXYMAT PSA oxygen generator — the Half Pallet Series starts at 44 LPM at 93% O₂ and 4 bar(g).

A self-contained oxygen concentrator that produces oxygen from air for tanks, holding systems and live transport.

Price range: $2,900.00 through $3,800.00 ex GST

Option

Clear

Categories: Oxygen & Ozone

Applications: Hatchery, Live Holding & Purging, LSS, Public Aquarium, RAS

Brand: AirSep

Product Information

Two models — Onyx at 5 LPM and 9 PSI, and Onyx Ultra at 10 LPM and 20 PSI, both at oxygen concentration up to 95.5%
Self-contained: the air compressor is built in, so there is no separate compressor, dryer or air line to install
Quiet at 49 dB, so it can sit in a hatchery room, aquarium plant room or clinic without noise treatment
Transportable on a sturdy roller base and microprocessor controlled for steady, unattended running
High-impact polystyrene enclosure; rated for 5°C to 40°C ambient and 0% to 95% relative humidity, non-condensing
Suits aquaculture, hatcheries, aquariums, hydroponics, veterinary and medical oxygen duties
Regulator and flowmeter manifolds are available separately to connect the Onyx to Clearwater ozone generators
Sizing: choose on the oxygen flow you need and the back pressure you have to push against — Onyx delivers 5 LPM against 9 PSI, Onyx Ultra 10 LPM against 20 PSI, so take the Ultra if you are feeding a diffuser, cone or ozone generator that needs more than about 9 PSI. Above 10 LPM, step up to an OXYMAT PSA generator.

Model	Code	Oxygen output	Outlet pressure	Power draw	Weight
Onyx	AS016-2	5 LPM at up to 95.5% O₂	9 PSI (62 kPa)	350 W	22 kg
Onyx Ultra	AS121	10 LPM at up to 95.5% O₂	20 PSI (138 kPa)	750 W	35 kg
Both models	—	Noise 49 dB	5°C to 40°C ambient	0% to 95% RH, non-condensing	Air compressor built in — no external air supply required

What oxygen purity does the Onyx produce?

Which model should I choose?

Do I need a separate air compressor?

How noisy is it?

Can I run it with an ozone generator?

What conditions can it operate in?

What if I need more than 10 LPM?
