Biostream BP100 (10″) Fish Pump

Q: How many fish will the BP100 move in an hour?

Up to 55 tonnes per hour through its 10″ bore, though the rate you actually achieve depends on species, fish size, pipe run and head.

Q: What size fish will it pass?

The BP100 is rated to a maximum average fish size of 2.7 kg.

Q: How high can it lift?

Up to 9 m of pumping head on the standard 25 hp BP100, or 11 m on the 30 hp BP100-S.

Q: How do I choose between the BP100 and the sizes either side of it?

Compare bore, fish size and tonnage together — the BP80 is 8″ bore, 1.5 kg fish and 24 t/hr, the BP100 is 10″ bore, 2.7 kg fish and 55 t/hr, and the BP120 is 12″ bore, 7 kg fish and 150 t/hr.

Q: What pipe bore does it run?

A 10 inch bore, which is what the BP100 designation refers to — ask us to confirm the metric bore and flange detail for your pipework.

Q: How much water and air does the pump need?

Water and air demand figures are not published for the BP100, so ask Fresh By Design to confirm the service requirements for your layout before you design the services.

Q: How do I get a price?

Request a quote with the tonnage you need to move per hour, your maximum average fish size and the vertical head from water level to discharge, and we’ll confirm the right BP model and lead time.

A fish pump for moving larger fish gently between tanks, ponds, cages and vehicles.

Categories: Fish Pumps

Applications: Live Holding & Purging, Live Transport, RAS

Brand: Biostream

Biostream BP100 (10") Fish Pump - Image 2

Biostream BP100 (10") Fish Pump - Image 3

Biostream BP100 (10") Fish Pump - Image 4

Product Information

Key Features

Purpose-built live aquatic transfer pump — moves fish without external or internal damage to the species
10″ suction and discharge bore, matched to fish up to a 2.7 kg average
Self-priming, with variable speed electric drive and optional remote control operation
Marine alloy aluminium construction, so it can be moved and reinstalled between tanks
Submersible and non-submersible application designs
Two drive options — 25 hp standard and 30 hp BP100-S — lifting to 9 m and 11 m respectively
Harvest-scale throughput for bathing, delousing, transferring, grading and harvesting, or as a permanent centralised transfer system
Sizing: the BP100 moves up to 55 tonnes of fish per hour through its 10″ bore at up to 9 m head, with a maximum average fish size of 2.7 kg — drop to the BP80 (8″ bore, 24 t/hr, 1.5 kg fish) for smaller stock, or step up to the BP120 (12″ bore, 150 t/hr, 7 kg fish) for full harvest duty, and size on your worst case, as these limits cannot be achieved simultaneously

Specifications

Specification	Detail
Model	BioStream BP100 (BP100-S high-head variant available)
Suction and discharge bore	10″ — the BioStream brochure prints this as 300 mm; confirm the metric bore with Fresh By Design before you order pipework
Fish pumping capacity	Up to 55 tonnes per hour
Maximum average fish size	2.7 kg
Maximum pumping head	9 m — BP100-S: 11 m
Main pump drive	25 hp — BP100-S: 30 hp
Drive type	Variable speed electric drive, self-priming
Remote control	Available as an option
Construction	Marine alloy aluminium
Weight	Not published by supplier — confirm with Fresh By Design
Application design	Submersible and non-submersible
Water flow required	Not published by supplier — confirm with Fresh By Design for your layout
Air supply required	Not published by supplier — confirm with Fresh By Design for your layout
Other sizes in the range	BP25 (2.5″), BP40 (4″), BP60 (6″), BP80 (8″), BP120 (12″), BP140 (14″) — other sizes available on request
Please note	Limits vary with application, species and setup, and cannot be achieved simultaneously

Downloads

BioStream Brochure BioStream Fish Pumps BioStream Applications

Frequently Asked Questions

How many fish will the BP100 move in an hour?

What size fish will it pass?

How high can it lift?

How do I choose between the BP100 and the sizes either side of it?

What pipe bore does it run?

How much water and air does the pump need?

How do I get a price?
