Biostream BP120 (12″) Fish Pump

Q: How many fish will the BP120 move in an hour?

Up to 150 tonnes per hour through its 12″ bore, though the rate you actually achieve depends on species, fish size, pipe run and head.

Q: What size fish will it pass?

The BP120 is rated to a maximum average fish size of 7 kg.

Q: How do I choose between the BP120 and the sizes either side of it?

Compare bore, fish size and tonnage together — the BP100 is 10″ bore, 2.7 kg fish and 55 t/hr, the BP120 is 12″ bore, 7 kg fish and 150 t/hr, and the BP140 is 14″ bore, 9 kg fish and 200 t/hr.

Q: Can it be used on a boat?

Yes — the BP120 is hydraulically driven, which is what lets it run anywhere from an indoor RAS to a boat deck.

Q: How much water and air does the pump need?

Water and air demand figures are not published for the BP120, so ask Fresh By Design to confirm the service requirements for your layout before you design the services.

Q: How do I get a price?

Request a quote with the tonnage you need to move per hour, your maximum average fish size and the vertical head from water level to discharge, and we’ll confirm the right BP model and lead time.

A high-capacity fish pump for moving large fish between ponds, cages, vessels and processing.

Categories: Fish Pumps

Applications: Live Holding & Purging, Live Transport, RAS

Brand: Biostream

Biostream BP120 (12") Fish Pump - Image 2

Biostream BP120 (12") Fish Pump - Image 3

Biostream BP120 (12") Fish Pump - Image 4

Product Information

Key Features

Purpose-built live aquatic transfer pump — moves fish without external or internal damage to the species
12″ suction and discharge bore, matched to fish up to a 7 kg average
Hydraulically driven, so it works equally well in an indoor RAS or on a boat deck
Marine alloy aluminium construction, so it can be moved and reinstalled between sites
Submersible and non-submersible application designs
Broad operating range for bathing, delousing, transferring, grading and harvesting
Two to three times more fish per hour than manual handling, with less damage and stress to the product
Sizing: the BP120 moves up to 150 tonnes of fish per hour through its 12″ bore at up to 8 m head, with a maximum average fish size of 7 kg — drop to the BP100 (10″ bore, 55 t/hr, 2.7 kg fish) for smaller stock, or step up to the BP140 (14″ bore, 200 t/hr, 9 kg fish) for the largest harvest duty, and size on your worst case, as these limits cannot be achieved simultaneously

Specifications

Specification	Detail
Model	BioStream BP120
Suction and discharge bore	12″ — metric bore not published by supplier; confirm with Fresh By Design
Fish pumping capacity	Up to 150 tonnes per hour
Maximum average fish size	7 kg
Maximum pumping head	8 m
Drive type	Hydraulically driven
Main pump drive rating	Not published by supplier — confirm with Fresh By Design
Construction	Marine alloy aluminium
Weight	Not published by supplier — confirm with Fresh By Design
Application design	Submersible and non-submersible; indoor RAS through to boat decks
Typical duties	Bathing, delousing, transferring, grading and harvesting
Water flow required	Not published by supplier — confirm with Fresh By Design for your layout
Air supply required	Not published by supplier — confirm with Fresh By Design for your layout
Other sizes in the range	BP25 (2.5″), BP40 (4″), BP60 (6″), BP80 (8″), BP100 (10″), BP140 (14″) — other sizes available on request
Please note	Limits vary with application, species and setup, and cannot be achieved simultaneously

Downloads

BioStream Brochure BioStream Applications

Frequently Asked Questions

How many fish will the BP120 move in an hour?

What size fish will it pass?

How high can it lift?

How do I choose between the BP120 and the sizes either side of it?

Can it be used on a boat?

How much water and air does the pump need?

How do I get a price?
