Precision-woven monofilament nylon filter mesh with uniform, repeatable apertures, stocked from 1 to 1,000 microns and cut to the metre or supplied as a whole roll. Suits brine shrimp and rotifer culture, plankton nets, pipe screens, filter bags and intake or effluent screening. Other apertures are available on request.
Price range: $100.00 through $250.00 ex GST
Categories: Hatchery, Mechanical Filtration
Applications: Hatchery, RAS, Water & Wastewater Treatment
| Aperture | SKU | Roll width | Notes |
|---|---|---|---|
| 1 µm | NM1 | 115 cm | Finest stocked aperture |
| 25 µm | NM25 | 102 cm | Larval and live-feed screening |
| 50 µm | NMM50 | 127 cm | Rotifer and micro-algae work |
| 65 µm | NM65 | 229 cm | Medical grade; widest stocked roll |
| 100 µm | NMM100 | 127 cm | General fine filtration |
| 125 µm | NM125 | 136 cm | General fine filtration |
| 177 µm | NMM177 | 127 cm | Artemia and live-feed harvest |
| 300 µm | NMM300 | 127 cm | Pre-filtration and filter bags |
| 500 µm | NMM500 | 127 cm | Pre-filtration and pipe screens |
| 700 µm | NM700 | 112 cm | Coarse screening |
| 1,000 µm | NMM1000 | 127 cm | Coarsest stocked aperture; intake screening |
| Other apertures | On request | Up to 229 cm | The manufacturing range runs from 1 µm to 2,000 µm — other apertures available on request |
| Material | — | — | Monofilament nylon wire, PA6 or PA66; plain or twill weave |
| Open area | — | — | Varies with aperture and weave; 48% at 200 µm is the published worked example |
| Compliance | — | — | FDA, EC Regulation No 1935/2004, EU Regulation No 10/2011 |
| Supplied as | — | — | Cut per metre, or as a whole roll |
